Details
| Inner Diameter | 20 |
| Outer Diameter | 36 |
| Thickness | 1.5 |
| Surface Style | Diamond Indentations |
Material Specification
| Structure | CuSn8 bronze with either grease pockets or holes |
|---|---|
| PV (N/mm² x m/s) | 2.8 max |
| Static load (N/mm²) | 120 max |
| Dynamic load (N/mm²) | 40 max |
| Sliding speed – With Grease (m/s) | 2.5 max |
| Intermittent temperature (°C) | 130 max |
| Operating temperature (°C) | -100 to 200 |
| Thermal Conductivity (W/mk) | 60 |
| Coefficient of friction | 0.08 to 0.25 |
| Hardness (HB) | 90-120 |
| Tensile strength (N/mm²) | 450 min |
| Yield point (N/mm²) | 250 min |
| Elongation (%) | 40 |
Tolerances & Fittings (Metric)
| Min | Max | Tolerance | |
|---|---|---|---|
| Thickness Tolerance | 1.44 | 1.5 |
